power supplies - Pwr sup.unit pulse, 154.2W, 5VDC, 24VDC, 12VDC, 15A, 3A, 0.6A, 900g

Prod code: 17288

TP-150-D PDF

TP-150-D

Price:  86.41 €
VAT:  20.74 €
Final price with tax:  107.15 €
Amount:
Warning Long delivery time
Specifications
Manufacturer MEAN WELL
Pwr sup. unit type switched-mode
Kind of power supply modular
Power 154.2W
Output voltage 5V DC
Output voltage 2 24V DC
Output voltage 3 12V DC
Output current 15 (2...20)A
Output current 2 3 (0.4...4)A
Output current 3 0.6 (0...1)A
Supply voltage 90...264V AC, 127...370V DC
Weight 900g
Electrical connection terminal block
Protection overload, voltage growth, short-circuit
Mounting for building in
Number of outputs 3
Operating temperature 10...60°C
Body dimensions 199 x 99 x 50mm
Power supply/converter features rated parameters obtained at full load
Series TP-150
Efficiency 78%
Case type 916B
Additional functions active PFC
Associated items DRL-02, DRP-02A, MHS-012
Dimensions  VIEW

Availability: With order
