Transformers PCB - Encapsulated trafo, PCB mount, 16VA, 230/2x9V

Prod code: 9815

TSZZ16/2X9V PDF

TSZZ16/2X9V

Price:  10.74 €
VAT:  2.58 €
Final price with tax:  13.32 €
Amount:
Usually shipped within 2-3 business days.
Specifications
Manufacturer INDEL
Transformer type encapsulated
Power 20VA
Primary voltage 230V AC
Secondary voltage 1 9V
Secondary voltage 2 9V
Secondary winding current 1 1.11A
Secondary winding current 2 1.11A
Mounting PCB
Pri./sec. insulation strength 4kV/60s
Sealing IP00
Conform to the norm PN-EN 61558
Thermal class Ta40B
Secondary winding terminals 8-9, 13-14
Primary winding terminals 1-7
Insulation class II
Weight 550g
A dimension 58.8mm
A1 dimension 40.2mm
B dimension 49.8mm
B1 dimension 38.6mm
C dimension 42.2mm
C1 dimension 33.8mm
D dimension 65mm
D1 dimension 37.5mm
M dimension 30mm
P dimension 5mm
Dimensions  VIEW
Schematic diagram  VIEW

Availability: With order
