Humidity Sensors - Sensor temperature and humidity sensor, digital, ±2%, Case SIP4

Prod code: 23960

HIH8120-021-001 PDF

HIH8120-021-001

Price:  16.97 €
VAT:  4.07 €
Final price with tax:  21.04 €
Amount:
Usually shipped within 2-3 business days.
Specifications
Manufacturer HONEYWELL
Sensor type temperature and humidity sensor
Sensor type digital
Measuring range 0...100% RH
Tolerance 2%
Supply voltage 2.3...5.5V DC
Case SIP4
Output configuration I2C
Operating temperature 40...125°C
Series HumidIcon
Mounting THT
Manufacturer series HIH8000
Dimensions  VIEW

Availability: With order
