Pwr sup.unit pulse, 65W, 5VDC, 15VDC, -5VDC, -15VDC, 10A, 4A, 1A - 37.62 EUR : acdcshop.gr


power supplies - Pwr sup.unit pulse, 65W, 5VDC, 15VDC, -5VDC, -15VDC, 10A, 4A, 1A	Prod code: 17274
PDF	RQ-125C

Click to enlarge Pwr sup.unit pulse, 65W, 5VDC, 15VDC, -5VDC, -15VDC, 10A, 4A, 1A

Price:	37.62 €
VAT:	9.03 €
Final price with tax:	46.65 €
Amount:
Long delivery time Long delivery time

Specifications
Manufacturer	MEAN WELL
Pwr sup. unit type	switched-mode
Kind of power supply	modular
Power	65W
Output voltage	5V DC
Output voltage 2	15V DC
Output voltage 3	5V DC
Output voltage 4	15V DC
Output current	10 (2...12)A
Output current 2	4 (0.5...4)A
Output current 3	1 (0.1...1)A
Output current 4	0.5 (0...1)A
Supply voltage	88...264V AC, 248...373V DC
Weight	700g
Electrical connection	terminal block
Protection	overload, voltage growth, short-circuit
Mounting	for building in
Number of outputs	4
Operating temperature	20...70°C
Body dimensions	199 x 98 x 38mm
Power supply/converter features	rated parameters obtained at full load
Series	RQ-125
Efficiency	80%
Case type	902
Associated items	DRL-02, DRP-03A
Dimensions	VIEW

Availability: With order
